PVC coated chain-link fence
PVC coated chain-link fence always complies with DSTU EN 10223-6:2001 Steel wire and wire products for fencing. Part 6. Steel wire chain link fencing. Specifications. (EN 10223-6: 1998, IDT).
PVC coated chain link fence is characterized by the high tensile strength and resistance to environmental factors.Due to PVC coating and zinc pre-coating, it is ideal for outdoor use, having UV radiation protection for over a 10-year period, acid rains and sea-breeze protection. Low temperature resistance guarantee is up to -25˚С.
Note! We put PVC coating ONLY on galvanized steel wire.
Grid appearance remains the same in the course of time (painting is not required). The grid has high level of fire safety (it is not ignite or burn). It is widely used for landscape design, fencing of individual land plots, fencing of sport grounds (tennis courts, football fields), playgrounds, gardens, etc.
Our equipment for PVC coated chain-link fence 4-meter long
Technical specifications
Standard grid color: green RAL6005, grey RAL 7024 (other colors are also possible)
Material: low carbon steel wire, galvanized with PVC coating
Wire diameter:
1,45 / 2,5 mm (1,45 mm – diameter of galvanized wire, 2,5 mm – diameter of PVC coated wire)
1,65 / 2,5 mm
1,8 / 2,8 mm
1,9 / 3,0 mm
2,0 / 4,0 mm
3,0 / 4,0 mm
Roll height: from 1 to 4 m
Note! The roll height can be 4 meter in one cloth (we have special equipment to produce such height). Look at photos.
Roll length: 10 m, 15 m, 20 m, 25m
Mesh size: from 20 to 75mm
Grid warranty: 10 years
PVC coated chain-link fence 4-meter long (standard)
PVC coated chain-link fence 4-meter long (compact)
Loading
PVC coated chain-link fence is supplied on pallets. There are two variants of arranging rolls:
compact method (possible to deliver up to 22 tons brutto (up to 1,5 tons per one pallet).
Note! Rolls are packed in a compact way automatically.
standard or classic method (possible to deliver 15-17 tons brutto).
Packing
Upon request, the rolls edges can be packed in polyethylene packets.
Rolls of PVC coated chain-link fence (compact)
Rolls of PVC coated chain-link fence (standard)
